Laboratory Testing

Laboratory Soils Testing

Also available:

• Department of the Army (1986) — Laboratory Soils Testing (for download)
• Calibration of Laboratory Soils Testing Equipment, EM 1110-2-1909, 1 December 1970
• Liquid Limit Grooving Tools, EP 1110-1-9, 26 February 1982

USACOE EM 1110-2-1906
20 August 1986

This manual presents recommended testing procedures for making determinations of the soil properties to be used in the design of civil works projects. It is not intended to be a text book on soils testing or to supplant the judgement of design engineers in specifying procedures to satisfy the requirements of a particular project. Test procedures included are the following:

• WATER CONTENT – GENERAL
• UNIT WEIGHTS, VOID RATIO, POROSITY, AND DEGREE OF SATURATION
• LIQUID AND PLASTIC LIMITS
• ONE-POINT LIQUID LIMIT TEST
• SHRINKAGE LIMIT TEST
• GRAIN-SIZE ANALYSIS
• COMPACTION TESTS
• COMPACTION TEST FOR EARTH-ROCK MIXTURES
• PERMEABILITY TESTS
• CONSOLIDATION TEST
• SWELL AND SWELL PRESSURE TESTS
• DRAINED (S) DIRECT SHEAR TEST
• DRAINED (S) REPEATED DIRECT SHEAR TEST
• TRIAXIAL COMPRESSION TESTS
• CYCLIC TRIAXIAL TESTS
• DETERMINATION OF CRITICAL VOID RATIO
• UNCONFINED COMPRESSION TEST
• MODIFIED PROVIDENCE VIBRATED DENSITY TEST
• PINHOLE EROSION TEST FOR IDENTIFICATION OF DISPERSIVE CLAYS

Materials Testing

We also have the previous edition of this (FM 5-530) available for download here.

Field Manual FM 5-472
NAVFAC MO-330
AFJMAN 32-1221 (I)
1 July 2001 (Change 2)

This manual provides the technical information necessary for military personnel to obtain samples and perform engineering tests and calculations on soils, bituminous paving mixtures, and concrete. These tests and calculations are required to achieve proper design with these materials and adequate control over their use in military construction.

This manual covers soils, aggregates, bituminous cements, bituminous paving mixtures, Portland cement concrete, and stabilized soil including stabilizing agents such as bitumens, cements, lime, fly ash, and chemical modifiers. The manual gives detailed instructions for taking adequate representative test samples and step-by-step procedures for making physical properties tests and for recording, calculating, and evaluating the test results. The manual explains methods for designing bituminous paving mixtures and Portland cement concrete and ways of stabilizing soil. It also gives the procedures and tests required to control the manufacture of these mixtures. The manual describes the tools and equipment for performing these tests and contains general instructions for the care, calibration, and use of test equipment.

---

Evaluation of Laboratory Compaction Procedures for Specification of
Densitites for Compacting Fine Sands

Brad J. Arcement and Stephen G. Wright
Center for Transportation Research
The University of Texas at Austin
Report No. FHWA/TX-02/1874-1
January 2001

TxDOT utilizes a number of sources of cohesionless soils as fill materials for embankment construction and as backfill for mechanically stabilized earth (MSE) walls. Some problems have been experienced with these materials in the past, especially with settlements of backfills behind retaining walls. The objective of this project was to develop recommendations for compaction of cohesionless soils used as backfill materials. Emphasis was placed on uniform fine sands, which are used throughout a broad area of the State as fill materials.

Fourteen cohesionless soils from around Texas were selected for laboratory testing. The majority of these soils were classified as uniform fine sands and silty sands. The selected soils were compacted using the following compaction procedures:

• TxDOT’s Tx 113-E – Laboratory Compaction Characteristics and Moisture-Density Relationship of Base Materials
• ASTM D 1557 – Laboratory Compaction Characteristics of Soil Using Modified Effort
• British Standard BS-1377 – Vibrating Hammer Method
• ASTM D 4253 – Maximum Index Density and Unit Weight of Soils Using a Vibratory Table

Based on the results of these tests as well as additional tests to measure the compressibility of the soil, recommendations were made for compaction.

For uniform fine sands like those tested in this study it is recommended that they be compacted to 95 percent of the Modified proctor (ASTM D 1557) maximum dry unit weight for application where settlements are important to performance. It is also recommended that sufficient moisture be added to minimize settlements; compaction too dry can still result in excessive settlement even when the soil is compacted to the stated density. Alternative compaction recommendations are also presented based on TxDOT’s Tx 113-E compaction procedure. However, this procedure is judged to be much more complex and less desirable than the ASTM D 1557 procedure.

Geotechnical Centrifuges Observed in the Soviet Union, 6-29 September 1979

Paul A. Gilbert
Geotechnical Laboratory, U.S. Army Engineer Waterways Experiment Station
Miscellaneous Paper GL-82-8
August 1982

In 1979 a team of U. S. geotechnical engineers visited the U.S.S.R. to demonstrations of centrifuge devices and to discuss soil modelling techniques with representatives of the Soviet Union. This report presents details of the visit and an assessment of centrifuge modelling research in the Soviet Union.

Laboratory Investigations of Cohesionless Shear Strength in Low Confinement Environments

Katherine E. Winters, Oliver-Denzil S. Taylor, Woodman W. Berry, Amy L. Cunningham, Wesley R. Rowland, and Mark D. Antwine
U.S. Army Corps of Engineers, Engineer Research and Development Centre
ERDC/GSL TR-18-22
August 2018

In low-confining stress environments, Mohr-Coulomb failure mechanics implies that a cohesionless soil has negligible shear strength. This report presents results of total stress laboratory investigations from triaxial and simple shear loadings for three loose- to medium-dense, cohesionless materials, i.e., a poorly-graded sand (SP), a silty sand (SM), and a silt (ML), at confining pressures ranging from zero to 1,000 kPa, as well as cyclic ring shear testing of the SP material at confining pressures from 10 to 100 kPa. All materials exhibited shear strengths and stress paths in excess of expected failure surfaces at confining pressures under 100 kPa. The data indicate that cohesionless soils exhibit significant soil fabric strength characteristics that are not captured by the standard internal friction angle definition, as evidenced by the shear stress intercept of the trendlines relating shear strength and confining pressure. Under low confinement, the continuum fabric dominates the angle of the Mohr envelope. The significant difference in the Mohr envelope shape illustrates that the internal fabric’s ability to resist different loading mechanisms cannot be assumed by a linear approximation.

Laboratory Techniques and Procedures Using Lidar

Gary L. Bell, Jeremy A. Sharp, Tate O. McAlpin, Anthony R. Jackson, and George B. Herring
U.S. Army Corps of Engineers
ERDC/CHL CHETN-VII-18
January 2018

This Coastal and Hydraulics Engineering Technical Note (CHETN) reviews the process of establishing effective and accurate techniques for the application of lidar in the laboratory with a large model domain and a need to accurately resolve issues such as local pier scour and bathymetry/topography changes. The application is for both terrestrial and line-scanning lidar.

Rapid Drying Soils with Microwave Ovens

Kevin J. Gaspard, P.E.
Louisiana Transportation Research Centre
LTRC Project No. 99-3GT

Soils are normally dried in either a convection oven or stove. Inspections of field and laboratory moisture content testing indicated that the typical drying durations for a convection oven and stove were, 24 hours and 60 minutes, respectively. The objectives of this study were to determine the accuracy and soil drying duration of microwave ovens. This was accomplished by testing soils with and without additives. The soils were tested with a convection oven (CO), computer controlled microwave oven (CMWO), standard microwave oven (SMWO), and stove. The convection oven was considered to produce the true moisture content and was, therefore, used as a basis for comparison for the results of the other devices. Based on appraisals of the results, the standard microwave oven is the most feasible device to use in drying soils.

Revised Rapid Soils Analysis Kit (RSAK) – Wet Methodology

Ernest S. Berney IV, Naveen B. Ganesh, and David R. Daily
U.S. Army Corps of Engineers Research and Development Center ERDC TR-18-1
January 2018

ERDC research on crater formation from detonation of improvised explosive devices identified the significance of soil type on crater shape and size. Military Explosive Ordinance Disposal (EOD) teams required an expedient means of classifying soil from small field samples, according to the Unified Soil Classification System, to help identify characteristics of buried explosives. The existing Rapid Soils Analysis Kit (RSAK), developed at ERDC, was modified to shrink its cube volume, improve its accuracy, and adapt it to the EOD mission. As such the RSAK was changed from a dry, pulverization-based (D-RSAK) system to a wet, wash-based (W-RSAK) system similar to that used in a commercial laboratory to improve accuracy of determining fines content. Modifications were focused on increasing speed and accuracy from the original D-RSAK. This report presents comparisons of classification results on 14 different soil types by both the traditional laboratory, dry-based and wet-based systems to demonstrate the strengths and weaknesses of the new W-RSAK procedure. The kit in its current configuration with the wet process was demonstrated to significantly improve classification estimations. Revised software to process the data obtained from the W-RSAK equipment was developed using Matlab and Android platforms to enable deployment on multiple software platforms.

Soils Engineering

Army Institute for Professional Development
EN-54537, Edition 7

The Soils Engineering Subcourse is designed to teach you how to determine soil strength of swelling, non-swelling, and free-draining soils using CBR; determine after soil emplacement, field density and moisture content; use test data to determine stabilizing agents, the quantities required, and the construction sequence for given soils; and, direct a deliberate soil survey. This subcourse is presented in five lessons:

1. Basic Soil Properties
2. Soil Classification and Field Classification Procedures
3. Soil Surveys
4. Field Control Procedures
5. California Bearing Ratio

Soils Sampling and Testing Training Guide for Field and Laboratory Technicians on Roadway Construction

Eugene R. Russell and Michael Renk
Kansas State University
Report No. K-TRAN: KSU-96-10
December 1999

This manual has been developed as a training guide for field and laboratory technicians responsible for sampling and testing of soils used in roadway construction. It was completed in conjunction with K-TRAN Project KSU-96-10, entitled “Pilot Study to Determine Personnel Certification and Training.”

The development and implementation of Quality Control/Quality Assurance (QC/QA) specifications by the Kansas Department of Transportation has been a driving force behind the development of a soils training and certification program. Soils training and certification will increase the knowledge of laboratory, production, and field inspectors. Both the owner agency and the contractor will benefit with an increased number of qualified personnel to perform acceptance and quality control functions. In addition, it is anticipated that this program and its standardized set of core tests will help to achieve certification reciprocity throughout the region. This manual is a guide for training personnel to perform the core soils tests they should understand in order to be certified.

The manual is based on ASTM and AASHTO test methods and procedures. During the 4th Annual FHWA Region 5 & 7 Training and Certification Workshop, a core content of ASTM and AASHTO tests for soil technician training was defined by the Soils Training Development Team. This training manual implements this core content for certification of laboratory soil field inspectors.

The Unified Soil Classification System

United States Army Corps of Engineers
Technical Manual TM 3-357
April 1960

The purpose of this manual is to describe and explain the use of the “Unified Soil Classification System” in order that identification of soil types will be on a common basis throughout the agencies using this system.

The program of military airfield construction undertaken by the Department of the Army in 1941 revealed at an early stage that existing soil classifications were not entirely applicable to the work involved. In 1942 the Corps of Engineers tentatively adopted the “Airfield Classification” of soils which had been developed by Dr. Arthur Casagrande of the Harvard University Graduate School of Engineering. As a result of experience gained since that time, the original classification has bean expanded and reviewed in cooperation with the Bureau of Reclamation so that it applies not only to airfields but also to embankments, foundations, and other engineering features.
